Mitsubishi Space Gear (L400) I (1994-2007)

Depending on the year of manufacture, the attachment points may differ.

Front bumper

The bumper is removed with a metal amplifier.

-open the hood.

-under the hood, unscrew the two screws, release from the latches and remove the grille.

-under the grille, unscrew the two screws that secure the metal amplifier.

-from the bottom take out the caps (inserted from the bottom up).

-turn the wheels to the side.

-in the wheel wells, unscrew one screw on each side that attach the corners of the bumper to the wings.

-from the bottom side, unscrew the two long bolts that secure the metal reinforcement to the body.

-we release the latch in the wings (pull the corners of the bumper towards you).

-with an assistant, remove the bumper (be careful not to break the wires).

-disconnect electrical connectors (if any).

Mitsubishi Space Gear (L400) I (1994-2007) front bumper attachment points

Mitsubishi Space Gear (L400) I (1994-2007) front bumper mounting scheme



Rear bumper

⇒Tips for removing bumpers and how to avoid breaking anything..⇐

-open the trunk lid.

-in the opening of the trunk, unscrew the four screws that secure the upper part of the rear bumper.

-unscrew one screw on each side that attach the corners of the bumper to the wings.

-take out the caps (inserted from the bottom up) that secure the lower part.

-with an assistant, carefully pull the bumper back (be careful not to break the wires).

-disconnect electrical connectors (if any).

rear bumper mounting points Mitsubishi Space Gear (L400) I (1994-2007)

Rear bumper mounting diagram Mitsubishi Space Gear (L400) I (1994-2007)
